Porte-outils
Halter IN-Line
Holders

H
C

A
L1 L2
A-A

F

L3
H1
d

15 M5
A
26
36

ML16

Compatible
d bars L3 F H1 C H L1 L2 Art. N°
32 8.5 37 6 - 17.5 5.5 ML16A-BHK4N-32R-D
BB4R…
4 37 13.5 42 6 - 17.5 5.5 ML16A-BHK4N-37R-D
BF4R…
42 18.5 47 6 - 17.5 5.5 ML16A-BHK4N-42R-D

ML16

Compatible
d bars L3 F H1 C H L1 L2 Art. N°
BB4R… 47 18.5 52.5 6 1 17 6 ML16A-BHK6N-47R-D
6
BF4R… 57 28.5 62.5 6 1 17 6 ML16A-BHK6N-57R-D

12.72
