<< TOP-Line <<< Main menu T OP -LINE
Tournage arrière
< Rückwärts drehen 753 / 763
Back turning
L R
R E L
0.5
3°
R
3° 1.5 4 20°
L R
TiAlN N (μk20) HTA HTiN HN (μk10) TiAlN N (μk20) HTA HTiN HN (μk10)
E L R Art. N° TiN Art. N° TiN
1.0 5 0 753-1.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 763-1.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
1.0 5 0.08 753-1.0-R08 Ŷ Ŷ Ŷ 763-1.0-R08 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.5 6 0 753-1.5 Ŷ Ŷ Ŷ 763-1.5 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.0 7.5 0 753-2.0 Ŷ Ŷ Ŷ 763-2.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.5 9 0 753-2.5 Ŷ Ŷ Ŷ 763-2.5 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
7XX-XX-B Sur demande pour serrage type B, voir page 1.03
Wahlweise mit B-Spannsystem, siehe Seite 1.03
On request for B clamping system, see page 1.03
Ŷ = disponible / verfügbar / available
1.107
Ƒ = selon disponibilité du stock / jenach Lagerverfügbarkeit / depending on stock availability
