Fonçage-tournage
< Einstechen und drehen 754 / 764
Grooving and turning

L R

R E L
1°

R
1° 8

L R

TiAlN N (μk20) HTiN HN (μk10) TiAlN TiAlX N (μk20) HTiN HN (μk10)
E L R Art. N° TiN HTA Art. N° TiN HTA
0.5 1.5 0 754-0.5 Ŷ Ŷ Ŷ 764-0.5 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
0.75 2 0 754-0.75 Ŷ Ŷ Ŷ 764-0.75 Ŷ Ŷ Ŷ Ŷ
0.8 2 0 - 764-0.8 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
0.95 3 0 754-0.95 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-0.95 Ŷ Ŷ Ŷ Ŷ
1.0 2.5 0 754-1.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-1.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
1.0 2.5 0.08 754-1.0-R08 Ŷ Ŷ Ŷ 764-1.0-R08 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.2 3 0 754-1.2 Ŷ Ŷ Ŷ 764-1.2 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.5 3 0 754-1.5 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-1.5 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
1.5 3 0.08 754-1.5-R08 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-1.5-R08 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.5 3 0.15 - 764-1.5-R15 Ŷ Ŷ Ƒ Ŷ Ŷ Ŷ
1.5 3 0.20 - 764-1.5-R20 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.8 4 0 754-1.8 Ŷ Ŷ Ŷ 764-1.8 Ŷ Ŷ Ŷ Ŷ
2.0 4 0 754-2.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-2.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
2.0 4 0.08 754-2.0-R08 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-2.0-R08 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.0 4 0.15 - 764-2.0-R15 Ŷ Ŷ Ƒ Ŷ Ŷ Ŷ
2.0 4 0.20 754-2.0-R20 Ŷ Ŷ Ŷ 764-2.0-R20 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.5 6 0 754-2.5 Ŷ Ŷ Ŷ 764-2.5 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.5 6 0.15 - 764-2.5-R15 Ŷ Ŷ Ƒ Ŷ Ŷ Ŷ
2.5 6 0.20 - 764-2.5-R20 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
3.0 6 0 754-3.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-3.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
3.0 6 0.08 754-3.0-R08 Ŷ Ŷ Ŷ 764-3.0-R08 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
3.0 6 0.15 - 764-3.0-R15 Ŷ Ŷ Ƒ Ŷ Ŷ Ŷ
3.0 6 0.20 754-3.0-R20 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 764-3.0-R20 Ŷ Ŷ Ŷ Ŷ
4.0 8 0 754-4.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ 764-4.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
7XX-XX-B Sur demande pour serrage type B, voir page 1.03
Wahlweise mit B-Spannsystem, siehe Seite 1.03
On request for B clamping system, see page 1.03
Ŷ = disponible / verfügbar / available
1.117
Ƒ = selon disponibilité du stock / jenach Lagerverfügbarkeit / depending on stock availability
