<< MODU-Line <<< Main menu MODU-LINE

Pièces de rechange
Ersatzteile ML12 / ML16
Spare parts

Vis et clés pour le serrage des plaquettes
Schrauben und Schlüsseln für WSP-Befestigung
Screws and keys for insert clamping
Porte-outils
Halter
Holders
ML…250
V-M4X9-T15 C-T15 - - -
ML…260
ML…330
V-M2.5X7.8-T8 C-T8 - - -
ML…340
ML…630
ML…640 V-M4X9-T15
ML…650 C-T15 - - -
ML…650RC V-M4X6.5-T15
ML…660 V-M4X9-T15
ML…730 V-M3X7-T8
ML…730RC V-M3X5.5-T8
V-M3X4.5-T8
ML…730RC-R04
V-M3X7-T8 C-T8 - - -
V-M3X4.5-T8
ML…730RC-SWISS-NANO
V-M3X7-T8
ML…740 V-M3X7-T8
ML…750 V-M4X9-T15
ML…750RC V-M4X7.3-T15
V-M4X5.6-T15
ML…750RC-R04
V-M4X7.3-T15
V-M4X5.6-T15 C-T15 - - -
ML…750RC-SWISS-NANO
V-M4X7.3-T15
ML…760 V-M4X9-T15
ML…770RC-SWISS-NANO V-M4X7.3-T15
ML…780 V-M4X9-T15
ML…SC…06 V-M2.5X5.8-T8 C-T8 - - -
ML…SC…09 V-M4X7-T15-ISO C-T15 - - -
ML…-SD…07 V-M2.5X7.8-T8
C-T8 - - -
ML…-SD…07-D V-M2.5X5.8-T8
ML12…-SDJ…11 V-M4X7-T15-ISO
ML12…-SDN…11 C-T15 - - -
V-M4X9-T15-ISO
ML16…-SD…11
ML…-SV…11 V-M2.5X7.8-T8
C-T8 - - -
ML…-SV…13 V-M3X7.3-T8-ISO
ML…-CUT16 - - CUT16RS-SET - -
ML…-CUT16-V - - CUT16LS-SET - -
ML…-CUT22 - - CUT22RS-SET - -
ML…-CUT16-V - - CUT22LS-SET - -
ML16...-ET… JET32 - - -
ML16...-ET... V-JET32 - - - V-M5X21-6P7-J C-6PEX-7.0
ML...-BHK V-BHK-M4X0.5-T8 - -

12.87
