Alésage-copiage
Ausbohren-kopieren BF4… / BF6… BCX
Boring chambering

8°
L3 20°
Ø min
20°
7°
R
T
L1

E D L2
C

R L

P P P P P
M M M
N N N N
S S S S S
L2 L2
BH4… BHS4… ZTAF ZTAXF ZTAF
D h5 Holder Ø min L1 BHY4… BHK4… T E C R L3 Art. N° ZN ZN
3.0 10 8.5 0.15 0.90 0.70 0.05 32 BF4R/L-1030-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
1.0
5.0 10 8.5 0.15 0.90 0.70 0.05 32 BF4R/L-1050-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
4.5 10 8.5 0.23 1.35 0.75 0.05 32 BF4R/L-1545-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
1.5
7.5 10 8.5 0.23 1.35 0.75 0.05 32 BF4R/L-1575-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
6.0 10 8.5 0.30 1.80 1.15 0.05 32 BF4R/L-2060-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
BH4… 2.0
BHS4… 10.0 15 13.5 0.30 1.80 1.15 0.05 37 BF4R/L-20100-BCX-R05 Ŷ Ŷ Ŷ Ƒ Ƒ
4
BHY4… 7.5 10 8.5 0.38 2.25 1.30 0.10 32 BF4R/L-2575-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
BHK4… 2.5
12.5 15 13.5 0.38 2.25 1.30 0.10 37 BF4R/L-25125-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
9.0 15 13.5 0.45 2.70 1.35 0.10 37 BF4R/L-3090-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
3.0
15.0 20 18.5 0.45 2.70 1.35 0.10 42 BF4R/L-30150-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
10.5 15 13.5 0.53 3.15 1.60 0.10 37 BF4R/L-35105-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
3.5
17.5 20 18.5 0.53 3.15 1.60 0.10 42 BF4R/L-35175-BCX-R10 Ŷ Ŷ Ŷ Ƒ Ƒ
L2 L2
BH6… BHS6… ZTAXF
D h5 Holder Ø min L1 BHY6… BHK6… T E C R L3 Art. N° ZTAF ZN ZTAF ZN
12.0 20 18.5 0.60 3.80 2.20 0.15 47 BF6R/L-40120-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
4.0
20.0 30 28.5 0.60 3.80 2.20 0.15 57 BF6R/L-40200-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
13.5 20 18.5 0.68 4.28 2.30 0.15 47 BF6R/L-45135-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
BH6… 4.5
BHS6… 22.5 30 28.5 0.68 4.28 2.30 0.15 57 BF6R/L-45225-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
6
BHY6… 15.0 20 18.5 0.75 4.75 2.40 0.15 47 BF6R/L-50150-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
BHK6… 5.0
25.0 30 28.5 0.75 4.75 2.40 0.15 57 BF6R/L-50250-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
16.5 20 18.5 0.83 5.15 2.60 0.15 47 BF6R/L-55165-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
5.5
27.5 30 28.5 0.83 5.15 2.60 0.15 57 BF6R/L-55275-BCX-R15 Ŷ Ŷ Ŷ Ƒ Ƒ
Ŷ = disponible / verfügbar / available
10.25
Ƒ = selon disponibilité du stock / jenach Lagerverfügbarkeit / depending the stock availability
