        Fraises en bout                                    Paramètres de coupe indicatifs
   <    Schaftfräser                                           Empfohlene Schnittwerte
        End mills                                               Standard machining data


      Matière                VC   0.50 - 2.0  2.0 - 4.0  4.0 - 6.0  6.0 - 8.0  8.0 - 12.0
      Werkstoff                                                                  TiAlN   DLC
      Material             (m/min)  fz (mm)     fz (mm)     fz (mm)     fz (mm)     fz (mm)     N  STF

      Acier de décolletage
      Automatenstahl    P  80 - 130  0.004-0.015  0.015 - 0.025  0.025 - 0.035 0.035 - 0.050 0.050 - 0.080  -  -
      Free-cutting steel
      Acier
      Stahl   < 600 N/mm 2  P  70 - 100  0.004-0.015  0.015 - 0.025  0.025 - 0.035 0.035 - 0.050 0.050 - 0.080  -  -
      Steel
      Acier
      Stahl   < 800 N/mm 2  P  70 - 100  0.004-0.015  0.015 - 0.025  0.025 - 0.035 0.035 - 0.050 0.050 - 0.080  -  -
      Steel
      Acier
      Stahl   > 800 N/mm 2  P  50 - 80  0.004-0.015  0.015 - 0.025  0.025 - 0.035 0.035 - 0.050 0.050 - 0.080  -  -
      Steel
      Acier trempé
      Gehärteter Stahl  -55HRC  H  60 - 90  0.002 - 0.008  0.008 - 0.015  0.012 - 0.020  0.020 - 0.025 0.025 - 0.030  -  -
      Hardened steel
      Acier trempé
      Gehärteter Stahl  +55HRC  H  40 - 70  0.002 - 0.008  0.008 - 0.015  0.012 - 0.020  0.020 - 0.025 0.020 - 0.030  -  -
      Hardened steel
      Inox
      Rostfreistahl     M  40 - 80  0.003 - 0.008  0.008 - 0.015  0.015 - 0.020  0.020 - 0.030 0.030 - 0.050  -  -
      Stainless steel

                            230 -
      Aluminium         N        0.003 - 0.010  0.010 - 0.025  0.025 - 0.030 0.030 - 0.050 0.050 - 0.080
                            320
      Cuivre, laiton, bronze  100 -
      Kupfer, Messing, Bronze  N  190  0.003 - 0.010  0.010 - 0.020  0.020 - 0.030 0.030 - 0.040 0.040 - 0.070
      Copper, brass, bronze
      Matière synthétique   250 -
      Synthetisches Material   N  500  0.005 - 0.030 0.030 - 0.050 0.050 - 0.080  0.080 - 0.100  0.100 - 0.200  -
      Synthetic material
      Métaux précieux
      Edelmetalle       N  90 - 150 0.003 - 0.015  0.015 - 0.025  0.025 - 0.030 0.030 - 0.050 0.050 - 0.080
      Precious metals
      Titane
      Titan             S  30 - 70  0.004 - 0.010  0.010 - 0.017  0.017-0.025  0.025 - 0.035 0.035 - 0.050  -  -
      Titanium
      Alliage de nickel
      Nickel-Legierung        S  30 - 60  0.003 - 0.008  0.008 - 0.015  0.015 - 0.020  0.020 - 0.025 0.025 - 0.040  -  -
      Nickel alloy
      Matière exotique
      Exotisches material  O  15 - 25  0.002 - 0.008 0.008 - 0.020 0.020 - 0.030 0.030 - 0.040 0.040 - 0.050  -
      Exotic material
     Avec revêtement, augmenter les valeurs de 20-30%              * Bien / Gut / Good
     Mit Beschichtung, Daten um 20-30% erhöhen                     ** Très bien / Sehr Gut / Very good
     With coating, increase data by 20-30%                         *** Excellent / Ausgezeichnet / Excellent




   14.54
