Fraises en bout de finition
< Schlicht Schaftfräser 3545
Finishing end mills
L2
D2 D1
L1
MD
VHM λ 45° Sharp 1.5xD1 Z=5
Corner
HM
TiAlN STF
D1 h10 L2 D2 h5 L1 Art. N° N
1.00 1.50 6.00 50 3545-1.0
2.00 3.00 6.00 50 3545-2.0
3.00 4.50 6.00 50 3545-3.0
4.00 6.00 6.00 50 3545-4.0
5.00 7.50 6.00 50 3545-5.0
6.00 9.00 6.00 50 3545-6.0
