T OP -LINE << TOP-Line <<< Main menu
Tronçonnage
< Abstechen 751 / 761
Parting off
L R
15°
E L
0.3°
0.3°
L R
TiAlN N (μk20) HTA HTiN HN (μk10) TiAlN TiAlX N (μk20) HTA HTiN HN (μk10)
E L Art. N° TiN Art. N° TiN
1.0 5 751-1.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 761-1.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
1.2 5 751-1.2 Ŷ Ŷ Ŷ 761-1.2 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
1.5 7.5 751-1.5 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 761-1.5 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
1.8 7.5 751-1.8 Ŷ Ŷ Ŷ 761-1.8 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.0 10 751-2.0 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 761-2.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
2.2 10 751-2.2 Ŷ Ŷ Ŷ 761-2.2 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
2.5 10 751-2.5 Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ 761-2.5 Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ Ŷ
3.0 10 751-3.0 Ŷ Ŷ Ŷ 761-3.0 Ŷ Ŷ Ŷ Ŷ Ŷ Ƒ Ŷ
7XX-XX-B Sur demande pour serrage type B, voir page 1.03
Wahlweise mit B-Spannsystem, siehe Seite 1.03
On request for B clamping system, see page 1.03
